Description
Ambient air-heated natural draft design
Natural draft ambient air vaporizers have no movable parts which result in zero operational expenses (OPEX) and low maintenance costs.
Ambient air-heated fan forced draft design
In addition to natural draft design, forced draft vaporizers have increased sent-out capacity due to the introduction of forced air over the tube bundle. Introduction of this rotating equipment results in increased OPEX and maintenance costs.
Pressure building vaporizer
To regulate and maintain pressure for the consistent withdrawal of cryogenic liquids and gases from the tanks, ambient pressure building vaporizers and cryogenic pressure building coils are utilized to a re-gasify certain volume of cryogenic Liquid using latent heat of vaporization to maintain pressure on the type of cryogenic storage tank, transportation tankers. This enables the discharge of cryogenic liquid from the storage tank at the required flow and pressure.
HALSKE offers this equipment with a variety of flow rates and configurations to build up your requirements.
Features & Benefits
Smaller design and footprint for cost saving in raw material, transportation, and space
High-quality material and components
High efficiency and productivity
No running cost
Low maintenance
Easy installation and operation
Eco friendly
Specifications
No visible corrosion due to full aluminum design
Standard pressure range up to 40 bar g
Flow rates range from 200 – 5000 Nm3/h
Working Temperature: -250 °C to +38 °C
Discharge Gas Temperature: Approx. within -7 °C of ambient conditions (standard)
For an 8-hour performance
Fluid Passages: 6063 aluminum
External Fins: 6063 aluminum alloy
Frame Assembly: Type 6061 aluminum alloy
Extrusion lengths ranging from 1m to 6m
Applications include N2, O2, AR, and CO2 (please contact us for your other specific applications)
Manifold designs to suit pressure drop specifications
I/O Connections: NPT B.1.20.1/3 or Flanged B16.5 ANSI/ASME
